GC Image LCxLC-HRMS Edition, Release 2.9, is distributed for installation on computer systems running a Microsoft Windows Vista or a later operating system, including Windows 7 and Windows 10. The suggested minimum hardware configuration is a 1000MHz Intel Pentium 4 (or comparable) CPU (a multi-core CPU is preferred), 1GB RAM (2GB or more RAM is preferred, especially for LCxLC-MS), 128MB OpenGL-capable graphics card (256MB or more is preferred), and color monitor with 1024x768 (or higher) resolution (or dual monitors). GC Image LCxLC-HRMS Edition requires relatively little hard-disk space (about 600MB with example images), but data processed by the system may require large disk capacity.
GC Image LCxLC-HRMS Edition system is bundled in a single, self-extracting executable file. The setup program is available via download or on a CDROM. When executed, the setup program will install the software in the directory specified by the user and will add a link to GC Image LCxLC-HRMS Edition in the Start->Programs list and a shortcut on the desktop.
Brief installation instructions are given here. For more complete instructions, visit the GC Image LCxLC-HRMS Edition download page.
To install the GC Image LCxLC-HRMS Edition:
To install GC Image LCxLC-HRMS Edition, the user must agree to the software license terms and conditions.
After the GC Image LCxLC-HRMS Edition installation is finished, the setup launches the installer for the WIBU-Key (USB plug for licensing) and the installer for the National Institute of Standards and Technology (NIST) MS Search (Version 2.0) Demonstration Program, with the demonstration subset of the NIST/EPA/NIH Mass Spectral Library. In order to use GC Image LCxLC-HRMS Edition, the WIBU-Key software must be installed. Use of the NIST software requires agreement to the terms and conditions of the NIST license.
The installation also creates a program for uninstalling the GC Image LCxLC-HRMS Edition and removing all of its files. The uninstall program is located in the directory where the GC Image LCxLC-HRMS Edition is installed.
After installation, LC Image can be executed from the GC Image LCxLC-HRMS Edition folder of the Start menu, from the desktop shortcut, or from the bin folder of the installation directory. LC Image can be executed only under license and requires a USB key with valid license, sold and distributed by GC Image, LLC.
If you purchased a new USB key or are upgrading from an older version, the program will ask you to activate the key for this release as shown in fig.licenseChk.
|fig.licenseChk: The License Check dialog with license options.|
Follow the instructions or execute the activation program from the "GC Image" program group in the "Start" menu (or from the bin folder in the GC Image installation folder). The activation program displays your USB key serial number and requires an activation code to activate the USB key. Once your USB key is activated you can restart LC Image.
After start-up, the software presents a login dialog. fig.login illustrates the Login dialog.
|fig.login: The Login dialog with username and password.|
GC Image LCxLC-HRMS Edition allows users to login with their current user accounts on the operating system by clicking Login with System button. If Always login with current system user account is checked, the software will login automatically instead of showing the login dialog the next time. This setting can be changed later through Configure Settings.
GC Image LCxLC-HRMS Edition also can maintain user accounts with password access separate from Windows. To set up a new account, click Add New User on the login dialog. The Add New User dialog asks for name, username, password, and secret question and answer to retrieve a forgotten password. After setting up an account, login by entering the username and password. To retrieve a forgotten password, click Forgot Password on the login dialog. Then, enter the username on the Forgot Password dialog, then click OK to be shown the secret question, then type the secret answer, and then click Get Password.
To exit the LC Image, select Exit from the File menu.
A Trial Version of GC Image LCxLC-HRMS Edition is available for limited-time use. When the trial version of GC Image LCxLC-HRMS Edition is first executed, it will display a trial license number and request an activation code. To obtain an activation code, contact GC Image, LLC with the license number, or click on Request Activation Online. fig.trialLicense illustrates the Trial License dialog.
|fig.trialLicense: The Trial License dialog with a license number.|
